Cnc Steel Bar Bending Centerbhi-Lsw32

Product Description

 Cnc Steel Bar Bending Centerbhi-Lsw32

TENSILE STRENGTH: Kg/mm2 45: Kg/mm2 65

BENDINGCAPACITY: 10-32 mm: 10-30 mm

MAX.BENDING ANGLE:'-120~180°

OPERATION:Automatic bending

MAX.LENGTH OF STIRRUP SIDE: 11mm

MIN.LENGTH OF STIRRUP SIDE: 700mm

BENDINGHEAD MOVING SPEED: 0.5-1m/sec

MAX.BENDING SPEED:72°/sec

INSTALLEDPOWER:14 KW

AIRPRESSURE:0.6 Mpa

AVERAGEELECTRIC CONSUPTION:5kw/h

WEIGHT:3.2 Tons

L—W—H:12000—2000—1600mm

UNITPRICE RUPEES:

CERTIFICATION: ISO 9001:2008

MACHINE FUNCTION:

Vertical STEEL BAR BENDING CENTER can be used inbuilding road and bridge construction, can processing 10-32mm steel bar.Dual-head structure, Bid-bending direction, double bending head working, highworking efficiency. Processed more graphics, Adopted CNC control, highprecision, intelligence work, saving human cost.

PRODUCT DESCRIPTION

Automaticwire bending system (CNC);

HighProcessing Efficiency: Two bending head can bend at the same time, 3 timesProcessing efficiency than human hand.

HighPrecision Processing: Using CNC controlled ,machining accuracy can becontrolled within ± 1 cmHigh Saving Bending Graphics: Large storage capacity can save 400 processinggeometric graphics, high degree automationSaving Human Cost: One Bending center operators job equals six ordinary smallbender operatorsHigh power feeding motor to ensure bending bar accuracyEasy to Operate: Just reading the required processing graphics , editparameters while bending, lower requirements for operators, and touch-screenconsole, easy to operate, and more fast;

Low FailureRate: All Electrical components are internationally renowned brands, system isworking with  well-knownenterprisesLong Working Life: Machine Rack, bush and pins, are using high-quality alloysteel with special treatment to ensure life and lower cost;

ISO9001:2008 certification.
